Installing Thermozel wood-fired pizza ovens
First of all, you need to determine which model size would be best for your kitchen. We can offer you three sizes of pizza ovens.65 cm ,80cm or 1m cooking surface. Second whether you need to place the oven in a corner or along a straight wall.Difference between the premium line and the classic line of ovens.
Classic line wood-fired ovens both the cooking area and the dome of the pizza oven are rounded. For installation in a corner, a round oven is preferable. Ovens from the premium line have square bases which is easier for installation because the base frames are usually square.In front of the premium line oven dome and base, you see little touch of corner firebricks that give you this authentic Greek style.The oven is made of three parts oven dome part one and the base have two sections that make up the cooking area.
Classic line ovens is better to place on concrete bases and premium line pizza ovens can be placed to stone blocks or metal frames.For the premium line ovens we have two standard bases available. Oven's base made of stone. Open metal frame on wheels with wooden self , and insulated base.
Ovens are made on the Mediterranean coast. Greek factory .Thermozel is one of the few companies in the world certified for producing open fireplaces.
All ovens are designed to operate outdoors, subject to weather conditions. However, we recommend that if the oven is outside in a climate where you have a winter season, you should cover your oven additionally with extra insulation.
Extra insulation with plaster will protect your oven from rain and cold.Oven without insulation stays warm 12 hours after heating.Oven with extra insulation can stay warm 24 hours after heating.. Installing a 30 or 50mm calcium cilicate board underneath the pizza oven is recommended since it prevents the heat from descending.
.For the premium line ovens we have two standard bases available. Oven's base made of stone. Open metal frame on wheels with wooden self , and insulated base
It is a option to install ceramic fiber blanket and ,metal net before sending out the oven.Then you only have to place the oven and make the final finishing layer with plaster
We can make the oven ready as well bu the transport is best if we install ceramic fiber blanket and you can add plaster if oven is placed and conection to the chimney made .If the final plastering layer is not done yet we can send oven dome and base in separately pallets it makes it is easier to lift. Chimney added 1m with hat. Metal frame has wheels ,wooden self and insulated floor to retain more heat.
Chimney markings
Single wall flue pipe T600 N1 W vm G500
Or going throw the roof double walled chimney T450 N1 W Vm G100
